Displacement: 470/520/565/750/820cc/rev
Max.differential pressure: 400~450 bar
| Series | HRP05 | |||||||
| Motor performance | ||||||||
| Displacement | cm3/rev. | 470 | 520 | 565 | 750 | 820 | ||
| Max.torque | Nm | 3366 | 3724 | 4047 | 4775 | 5220 | ||
| Min.stable speed | rpm | 5 | ||||||
| Max.speed | Displacement | rpm | 385 | 350 | 320 | 240 | 220 | |
| Variable displacement | rpm | 465 | 420 | 385 | 290 | 265 | ||
| Pressure | Max.differential pressure | bar | 450 | 400 | ||||
| Max.power | kW | 29 | 35 | |||||
| Weight | Singlespeed | With brake | kg | 54 | ||||
| Without brake | kg | 43 | ||||||
| Twospeed | With brake | kg | 60 | |||||
| Without brake | kg | 49 | ||||||
| Brake | ||||||||
| Static braking torque | Nm | 2200 | ||||||
| Release pressure | bar | 11 ～ 15 | ||||||
| Maximum pressure at brake port Z | bar | 30 | ||||||
| Oil volume to operate brake | cm3 | 23 | ||||||
